CNC Servo 3D Wood Router Machine Manufacturers In Mumbai

To set up a CNC Servo 3D Wood Router machine, place the machine on a stable, level, and vibration-free surface, then secure the frame by tightening all bolts and fasteners. Connect the servo motors, servo drives, controller, spindle, and emergency stop switch according to the wiring diagram. After completing the electrical connections, connect the machine to the control computer using USB or Ethernet, install the required CNC control software, power on the system, and run an initial system check to ensure all axes and components are functioning correctly.

How-To Guides

1. How to Set Up a CNC Servo 3D Wood Router

• Place the machine on a flat, vibration-free surface.
• Secure the machine frame and check all bolts.
• Connect the servo motors, drives, and controller properly.
• Connect the power supply and emergency stop switch.
• Install the CNC control software on the computer.
• Connect the machine to the computer via USB or Ethernet.
• Power on the machine and perform a system check.

2. How to Install and Configure Servo Motors

• Ensure power is turned off before wiring.
• Connect servo motors to their respective drives.
• Set servo parameters according to manufacturer specifications.
• Calibrate motor direction and rotation.
• Test motor movement using jog mode.
• Adjust acceleration and speed for smooth motion.

3. How to Prepare a 3D Design for Wood Routing

• Create or import a 3D model using CAD software.
• Check dimensions and scale the design if needed.
• Export the design as an STL or compatible file.
• Import the file into CAM software.
• Select appropriate cutting tools.
• Set cutting depth, feed rate, and spindle speed.
• Generate the toolpath and G-code.

4. How to Set Up the Workpiece

1. Clean the machine bed.
2. Place the wood material on the bed.
3. Secure the wood using clamps or vacuum table.
4. Ensure the material is level.
5. Set the machine origin (X, Y, Z zero point).
6. Double-check tool clearance.

5. How to Run a 3D Wood Routing Job

• Load the G-code into the CNC controller.
• Perform a dry run without cutting.
• Start the spindle and verify rotation speed.
• Begin the cutting process.
• Monitor machine movement and cutting quality.
• Pause immediately if abnormal sound or vibration occurs.

6. How to Maintain a CNC Servo Wood Router

• Clean dust and debris after each job.
• Lubricate linear rails and ball screws regularly.
• Inspect servo motor connections weekly.
• Check spindle bearings and cooling system.
• Tighten loose bolts and fittings.
• Update software and firmware when required.
